Mobile Grain Dryer are used to dry the maize grain so that it can be preserved and stored for a long time without any spoilage and can be consumed anytime.
We, Enoch’s Industries Pvt. Ltd. are the most prominent and well-renowned Mobile Grain Dryer manufacturer in Hyderabad, India the domain of Material handling equipment.
Specifications Of Mobile Grain Dryer
| SPECIFICATIONS | EMD 200 | EMD 300 | EMD 400 |
| Standard Equipment on All Models | Loading Hopper, Manual Unloading Head, Circulating Auger, PTO Tumbler Shaft, Dryer Controls, Grain Sampler, Access Door to Plenum, Vaporizer, Ladder | ||
| Standard Equipment On Individual Models | Two Tires, Four Jack Stands, Fan clutch | Two Tires, Four Jack Stands, Fan clutch | Four Tires, Six Jack Stands, Fan clutch |
| Drying Capacity ( 20.5 – 15.5%) | 2.0 Tonne/Hr. | 3.5 Tonne/Hr. | 5.0 Tonne/Hr. |
| Bin Capacity | 3.5 Tonne | 6.5 Tonne | 9.0 Tonne |
| Height to Top Of Auger W/ Vertical Head Option | (3.6 m) | (4.2 m) | (5.0 m) |
| Transport Height | (3.6 m) | (4.2 m) | (4.2 m) |
| Diameter Of Bin | (2.0 m) | (2.4 m) | (3.0 m) |
| Grain Wall Thickness | (45.7 cm) | (45.7 cm) | (45.7 cm) |
| Vertical Auger Diameter | (27 cm) | (30.5 cm) | (30.5 cm) |
| Overall Length | (4.1 m) | (4.1 m) | (4.8 m) |
| Size Of Burner BTU/ hr. (Max) | 1,27,900 (375 kw) | 2,200,000 (645 kw) | 3,000,000 (879 kw) |
| Fan Size and Type | 25” Centrifugal (63.5 cm) | 25” Centrifugal (63.5 cm) | 25” Centrifugal (63.5 cm) |
| Electric Motor Required | 15 HP, 1750 RPM (11.0 kw) | 20 HP, 1750 RPM (14.9 kw) | 25 HP, 1750 RPM (18.6 kw) |
| Weight, PTO Model | (850 kg) | (1250 kg) | (1650 kg) |
| PTO Speed | 475 RPM | 525 RPM | 525 RPM |
| Recirculating Time | 5-7 min | 10-12 min | 12-15 min |
| Loading Auger Size | 6” (15.0 cm) | 8” (20.3 cm) | 8” (20.3 cm) |
| Loading Rate | 20 Tonnes/ Hr. | 20 Tonnes/ Hr. | 20 Tonnes/ Hr. |
| Unloading Rate | 20 Tonnes/ Hr. | 20 Tonnes/ Hr. | 20 Tonnes/ Hr. |
| Fan Drive | Belt | Belt | Belt |
Our Presence
To maintain the trust of our customers and make them satisfy with our products we offer also offer customized products. To maintain the trust of our customers and make them satisfy with our products we offer also offer customized products at a very optimum cost. We have an in-house design facility of the latest software (solid works & Auto cad) along with an excellent manufacturing facility of CNC Cutting & Bending Machines which can meet customized requirements.
Being a proud exporter we serve our services to international countries which include Dubai, Indonesia, South Africa, Singapore, Bangladesh, Kuwait, Srilanka, UK, and Australia. We are also recognized as a versatile of Maize Dryer supplier in Pune and in various cities such as Kolkata, Lucknow, Bhilai, Indore, Mumbai, Nasik, Akola, Jalandhar, Ranchi, Durgapur, Jaipur, and Akola, Raigarh, and Jamshedpur
